Technical Specifications (Data Sheet)
| Parameter | Specification |
|---|---|
| Model Capacity | 15kW (On-Grid, Three-Phase) |
| Rated AC Output Power | 15,000W |
| Max DC Input Power | 22,500W |
| Max DC Input Voltage | 1100V |
| Nominal DC Input Voltage | 600V |
| MPPT Voltage Range | 200V – 1000V |
| Startup Voltage | 200V |
| Max DC Current (per MPPT) | 30A |
| Number of MPPT Trackers | 2 (2 strings per tracker) |
| Max. Efficiency | 98.6% |
| European Efficiency | 98.2% |
| Nominal AC Voltage | 400V (3 Phase, 50/60Hz) |
| AC Voltage Range | 310V – 480V |
| Rated AC Current | 22A |
| Power Factor Adjustment | 0.8 leading – 0.8 lagging |
| Total Harmonic Distortion (THD) | <3% |
| Cooling Method | Smart Fan Cooling |
| Communication Interfaces | RS485 / WiFi / Ethernet (Optional GPRS) |
| Protection Functions | Anti-Islanding, OVP/UVP, Overload, Short Circuit, Reverse Polarity, Ground Fault |
| Operating Temperature Range | -25°C to +60°C |
