Inverter Technical Specifications
| Specification | Details |
|---|---|
| MPPT Efficiency [%] | 99.90 |
| Max. Efficiency [%] | 97.90 |
| Euro-Efficiency [%] | 97.20 |
| PV Reverse Polarity Protection | YES |
| Battery Reverse Protection | YES |
| Anti-Islanding Protection | YES |
| Output Short Protection | YES |
| Leakage Current Protection | YES |
| Insulation Resistor Detection | YES |
| Over Voltage Category | III (AC), II (DC) |
| Reverse Connect Protection | YES |
| Over-Current/Over-Temperature Protection | YES |
| DC/AC Surge Protection | Type II (PV)/Type II (AC) |
| AFCI Protection | Optional |
| DC Switch | YES |
| Dimensions (WHD) [mm] | 600×450×226 |
| Packing Dimensions (WHD) [mm] | 665×545×390 |
| Net Weight [kg] | 34 |
| Gross Weight [kg] | 40 |
| Installation | Wall-mounted |
| Operating Temperature [°C] | -25 ~ +60 (Derating @45) |
| Storage Temperature [°C] | -40 ~ +70 |
| Relative Humidity [%] | 0 ~ 100 |
| Altitude [m] | <4000 (Derating >2000) |
| Protective Class | I |
| Ingress Protection | IP65 (Outdoor use) |
| Standby Consumption [W] | 20 ~ 25 |
| Standby Mode | YES |
| Cooling | Natural / Fan (depends on model) |
| Noise Grade [dB] | <40 / <55 |
| Inverter Topology | Non-isolated |
| Communication Interface | Ethernet, RS485, WiFi+LAN+BT, 4G (Optional), DRM, Ripple Control, USB, BMS (CAN), SG Ready |
| LCD Display | Backlight 16×4 character |
| Standard Warranty [year] | 10 |
| Button | Capacitive touch ×4 |
| Buzzer | 1 (EPS & Earth fault) |
| Battery Type | Lithium-Ion (LFP) |
| Battery Voltage [V] | 100 ~ 800 |
| Min. Battery Voltage [V] | 100 |
| Min. Battery Voltage @Full AC Load [V] | 50.0 |
| Max. Charge/Discharge Current [A] | — |
| Battery Communication Interface | CAN |
| Rated Grid Voltage [V] | 400/230Vac; 380/220Vac, 3L/N/PE |
| Rated Grid Frequency [Hz] | 50/60 ±5 |
| Power Factor | 1 (0.8 lead ~ 0.8 lag) |
| THDV [%] | <3 @ rated power |
| EPS Rated Voltage [V] | 400/230Vac; 380/220Vac, 3L/N/PE |
| EPS Rated Frequency [Hz] | 50/60 |
| Switch Time [ms] | <20 |
| EPS Max Current [A] (Per Phase) | Model dependent |
Models (Output & EPS Performance)
| Model | Output / EPS / Max Current |
|---|---|
| H3-5.0-Smart | AC Output 5000W, EPS 6000W, Max Current 7.6A |
| H3-6.0-Smart | AC Output 6000W, EPS 7200W, Max Current 9.1A |
| H3-8.0-Smart | AC Output 8000W, EPS 9600W, Max Current 12.1A |
| H3-9.9-Smart | AC Output 9900W, EPS 12000W, Max Current 15.0A |
| H3-10.0-Smart | AC Output 10000W, EPS 12000W, Max Current 15.2A |
| H3-12.0-Smart | AC Output 12000W, EPS 14400W, Max Current 18.2A |
| H3-15.0-Smart | AC Output 15000W, EPS 15000W, Max Current 22.7A |
