| Max. Input Power [W] |
6500 |
6500 |
8000 |
8000 |
4000 |
4000 |
5000 |
5000 |
5000 |
| Max. Input Voltage [V] |
1000 |
1000 |
1000 |
1000 |
1000 |
1000 |
1000 |
1000 |
1000 |
| Start-up Input Voltage [V] |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
160 |
| Rated Input Voltage [V] |
720 |
720 |
720 |
720 |
720 |
720 |
720 |
720 |
720 |
| MPPT Operating Voltage Range [V] |
160–950 |
160–950 |
160–950 |
160–950 |
160–950 |
160–950 |
160–950 |
160–950 |
160–950 |
| Max. Input Current [A] |
14 |
14 |
16 |
16 |
14 |
26 |
26 |
26 |
26 |
| Max. Short-circuit Current [A] |
14 |
14 |
16 |
16 |
14 |
26 |
26 |
26 |
26 |
| No. of Independent MPP Trackers |
1 |
1 |
2 |
2 |
1 |
1 |
2 |
2 |
2 |
| No. of Strings per MPP Tracker |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| Battery Type |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
Lithium (LFP) |
| Battery Voltage Range [V] |
180–600 |
180–600 |
180–600 |
180–600 |
180–600 |
180–600 |
180–600 |
180–600 |
180–600 |
| Max. Charge/Discharge Current [A] |
26 |
26 |
26 |
26 |
26 |
26 |
26 |
26 |
26 |
| Rated Output Power [W] |
5000 |
6000 |
8000 |
10000 |
5000 |
6000 |
8000 |
10000 |
12000 |
| Max. Output Apparent Power [VA] |
5500 |
6600 |
8800 |
11000 |
5500 |
6600 |
8800 |
11000 |
13200 |
| Peak Output Apparent Power (60s) [VA] |
10000 |
12000 |
14000 |
15000 |
10000 |
12000 |
14000 |
15000 |
15000 |
| Max. Output Current [A] |
7.2 |
8.7 |
11.6 |
14.5 |
8.0 |
9.6 |
12.8 |
16.0 |
19.2 |
| Rated Output Voltage [V] |
3L/N/PE 380/220; 400/230; 415/240 |
same for all |
|
|
|
|
|
|
|
| Rated Output Frequency [Hz] |
50/60 |
same for all |
|
|
|
|
|
|
|
| Power Factor |
1 (Adjustable 0.8 leading → 0.8 lagging) |
same for all |
|
|
|
|
|
|
|
| THDv (linear load) [%] |
<3 @ Rated Power |
same for all |
|
|
|
|
|
|
|
| Max. Efficiency [%] |
97.2 |
97.2 |
97.3 |
97.3 |
97.2 |
97.2 |
97.3 |
97.3 |
97.3 |
| Euro Efficiency [%] |
97.8 |
97.8 |
98.0 |
98.0 |
97.8 |
97.8 |
98.0 |
98.0 |
98.0 |
| Battery Charge Efficiency (PV → BAT) [%] |
98.5 |
same for all |
|
|
|
|
|
|
|
| Battery Discharge Efficiency (BAT → AC) [%] |
97.0 |
same for all |
|
|
|
|
|
|
|
| Dimensions (W×H×D mm) |
449×519×198 |
same for all |
|
|
|
|
|
|
|
| Weight [kg] |
28 |
same for all |
|
|
|
|
|
|
|
| Installation |
Wall-mounted |
same for all |
|
|
|
|
|
|
|
| Topology |
Transformerless |
same for all |
|
|
|
|
|
|
|
| Cooling Method |
Natural / FAN Cooling |
same for all |
|
|
|
|
|
|
|
| Noise Emission [dB] |
<45 |
same for all |
|
|
|
|
|
|
|
| Max. Operating Altitude [m] |
2000 |
same for all |
|
|
|
|
|
|
|
| Operating Temperature [°C] |
-25 ~ 60 |
same for all |
|
|
|
|
|
|
|
| Humidity [%] |
0–100 (no condensation) |
same for all |
|
|
|
|
|
|
|
| Ingress Protection |
IP65 |
same for all |
|
|
|
|
|
|
|
| Standby Consumption [W] |
<15 |
same for all |
|
|
|
|
|
|
|
| Monitoring Module |
WiFi, LAN, 4G, GPRS (Optional) |
same for all |
|
|
|
|
|
|
|
| Communication |
2×RS485, DRM, Ripple Control, USB |
same for all |
|
|
|
|
|
|
|
| Display |
LCD, App, Website |
same for all |
|
|
|
|
|
|
|
| Safety |
EN 62109-1, EN 62109-2, EN 62477-1 |
same for all |
|
|
|
|
|
|
|
| EMC |
IEC 61000-6-1, IEC 61000-6-3 |
same for all |
|
|
|
|
|
|
|
| Grid Regulation |
EN50549-1, C10/11, VDE-AR-N 4105, G98, CEI 0-21 |
same fo |
