| Rated output power |
8 000 VA / 8 000 W |
| Surge power |
16 000 VA |
| AC / output voltage (battery mode) |
230 VAC ±5% |
| Input AC voltage range (PC loads) |
170‑280 VAC |
| Input AC voltage range (home appliances) |
90‑280 VAC |
| Frequency |
50 Hz / 60 Hz (auto‐sensing) |
| Waveform |
Pure sine wave |
| Efficiency (peak) |
93% |
| Transfer time |
10 ms (PC loads), 20 ms (home appliances) |
| Battery voltage system |
48 VDC |
| Floating charge voltage |
~54 VDC |
| Over‑charge protection |
~63 VDC |
| Solar charger type |
MPPT (Maximum Power Point Tracking) |
| Maximum PV array power |
10 000 W |
| MPPT operating voltage range |
90‑450 VDC |
| Maximum PV open circuit voltage |
500 VDC |
| Maximum PV input current |
27 A × 2 (max 40 A) |
| Max solar charge current |
150 A |
| Parallel capability |
Up to 6 units |
| Dimensions (D × W × H) |
145 × 438 × 553.6 mm |
| Net weight |
~18.4 kg |
| Communication interfaces |
USB, RS232, RS485, WiFi; external current sensor port; optional GFCI / rapid shutdown / AFCI detection |
| Operating temperature & humidity |
10 °C to 50 °C; humidity 5% to 95% (non‑condensing) |
